| 加工定制：是 | 品牌：宇恒星光 | 型号：yhCWDM04 |
| 种类：波分复用器 |
| atures | Applications | ||
| Low Insertion Loss | CATV System | ||
| High Return Loss | CWDM/DWDM Module | ||
| High Reliability & Stability | Pon Networks | ||
| Specifications | |||
| Parameters | Unit | Values | |
| Type | nm | 1030/980 | |
| Transmission Wavelength | nm | 960~990 | |
| Reflection Wavelength | nm | 1020~1050 | |
| Max.Insertion Loss of Transmission Channel | dB | 0.8 | |
| Max.Insertion Loss of Reflection Channel | dB | 0.6 | |
| Min.Transmissionl ***lation@Reflection Wavelength | dB | 25 | |
| Min.Reflection ***lation@Transmission Wavelength | dB | 12 | |
| Max.Channel Flatness | dB | 0.4 | |
| Max.Polarization Dependent Loss | dB | 0.15 | |
| Max.Wavelength thermal stability | nm/鈩� | 0.003 | |
| Max.Insertion loss thermal Stability | dB/鈩� | 0.005 | |
| Min.Return Loss | N | 50 | |
| Max. Optical Power(CW) | W | 1,2,3,...,5,10 | |
| Fiber Type | - | Hi1060 | |
| Operating Temperature | 鈩� | 0~+70 | |
| Storage Temperature | 鈩� | -40~+85 | |
| For device with connector, IL is 0.3dB higher, RL is 5dB lower | |||
| Optical power will be only 1W with connector added | |||
